2017 Hinckley Picnic Boat 37 MKIII

Engine Make: Yanmar

Engine Model: 8LV370

Engine Year: 2016

Total Power: 370 hp

Engine Hours: 622

Engine Type: Inboard

Fuel Type: Diesel

Drive Type: Jet Drive

Engine Location: Port

Engine Make: Yanmar

Engine Model: 8LV370

Engine Year: 2016

Total Power: 370 hp

Engine Hours: 612

Engine Type: Inboard

Fuel Type: Diesel

Drive Type: Jet Drive

Engine Location: Starboard

Cockpit

• Optional Teak decks in cockpit

• Starboard transom door from swim platform with optional extra seating

• Optional lounge filler makes sun pad seating on port

• Swim platform clad in custom optioned fore/aft teak deck package

• Optional 18” deep insulated and drained cooler in port amenity with hinged lid

• Cockpit cushions upgraded

• Optional weather covers for cockpit seating

• Teak boarding step for port or starboard side deck

• Courtesy lights under side decks port and starboard

• Cockpit/pilothouse lockers with varnished louvered teak doors

• Cockpit shower with mixing valve at stern seat.

• Stamoid cockpit mooring cover

• Two speakers in cockpit with dedicated amplifier and volume control

• Four Optional stainless steel combination cup/rod holders mounted on the port and starboard side decks

• Two sets Optional Rupp rod holders mounted on port under gunwale

• Optional fresh water washdown in cockpit




Pilothouse

• Optional Varnished teak pilothouse liners and dash

• Optional teak decks throughout

• (4) Pilothouse windows with Green Tint include:  (2) Electric Sliding side windows and (2) Fixed, forward with heavy duty, self-parking, intermittent windshield wipers and fresh water washers

• Insulated white overhead has two optional (2) Electric opening oversized hatches with Ocean Air Sky screens/shades

• Stidd seats with Luxor Leather Soft Touch in Vellum for helmsman and navigator seats with integral folding foot rests

• Optional power adjustment for Stidd helm seat, fore/aft, up and down.

• Optional pilothouse table with removable stainless steel pedestal and canvas cover with storage bag.

• Optional 18” deep insulated and drained cooler in port amenity between cockpit and pilothouse with folding lid and storage below.

• Pilothouse cushions in upgraded Perennials Little Big Stripe Blue Boy upholstery at port and starboard

• Two 12,000 BTU air conditioning/reverse cycle heat units in pilothouse with separate controls for port and starboard.

• Additional illumination is by four (4) overhead low-voltage halogen lights

• Storage lockers under pilothouse settees

• (10) Cup holders, three at each settee and two at each helm location

• Glove box/storage at port and starboard helm shelves

• Varnished teak locking companionway door

• Varnished teak handrail on centerline

• Stamoid 3-piece drop curtains with Eisenglass windows

• Optional 110V AC waterproof outlet in pilothouse

• Optional USB charging jacks in lieu of standard cigarette style 12V jacks in side shelf locations.

Helm Station (Starboard)

• Varnished teak instrument pod

• Stainless steel 14” steering wheel with varnished wood rim

• Hinckley “JetStick II®” with H-Lock and Heading hold features

• Engine gauges, tachometer with hour meter, oil pressure, water temp., nozzle indicator

• Glove box/storage with lid at aft end of starboard shelf and USB jacks

• (2) Cup holders

Electronics and Navigation Equipment

• Upgraded Raymarine e165 16” color Chartplotter/Radar with 4kw 24” color HD scanner

• Raymarine P70R Autopilot interfaced to GPS

• i70 Multifunction instrument display with depth interfaced with Raymarine equipment

• Standard Horizon Explorer Gx1600BVHF radio with RAM mic

• Compass: Ritchie, mounted at helm dash

• Racor fuel filter/water audible alarm with indicators for generator main engines

• High water bilge alarm with indicators for each bilge zone (3)

• ACR remote spotlight control

• Optional Hinckley OnWatch vessel monitoring system.

• Independent climate controls at port and starboard helm

Entertainment Electronics

• Marine Starlink System for high speed WiFi

• New Fusion Sound System with enhanced bluetooth connectivity for additional range and performance

• Independent volume controls for pilothouse and cockpit at helm

• (2) Pair of speakers – (1) pair in pilothouse forward and (1) pair in cockpit.  All speakers have remote volume control

Galley (Port)

• Custom Corian “Witch Hazel” countertop in galley

• Stainless steel sink with Grohe fixtures, spray nozzle and hot and cold pressure water.

• Adler Barbour refrigeration – 12-volt cold plate refrigerator in a self-draining insulated box

• 110-volt outlet

• Built-in bin for dish stowage

• (3) Cherry pullout drawers

• Red step-light in galley

• Under counter pull-out garbage receptacle

• Additional storage is provided outboard and under the galley sink.

• A “pantry” locker with louvered door and several shelves separates the galley from the forward V-berth area and houses the stereo system.

Head (Next aft starboard)

• Solid cherry door panel door

• Custom satin varnished cherry countertop and under-mounted porcelain sink.

• Grohe faucet/hand held shower provides hot & cold pressure water – bracket for shower bulkhead mounted

• Sealand Vacu-Flush electric marine head is plumbed to a 27-gallon holding tank and overboard discharge

• Mirror on the forward bulkhead with cherry frame.

• Storage is provided by cherry faced lockers above and outboard the vanity, a drawer with a cherry face beside the marine head, and a locker under the vanity.

• 110-volt outlet

• Air conditioning/heat outlet in head

• Opening port with screen, as well as forced ventilation.

• Stainless steel towel bar

Island Queen Berth  (Forward)

• Island Queen berth with settee to port for easy access to the bunk.

• Storage lockers under Island Queen berth have easy-access cherry front drawers

• Cedar-lined hanging locker is just aft of the berths to starboard.

• Custom shear lockers located to port and starboard for additional storage

• Overhead Stainless Steel opening hatch with Ocean Air Sky screen/shade.

• Air conditioning/heat outlet in cabin with zone control located at galley aft face

• Mattress cover upholstered in upgraded Perennials Sticks Blue Boy fabric

• Cabin seat upholstered in upgraded Perennials Tisket Tasket fabric

Electrical

• 12 Volt System:

• Optional 9 KW Onan generator with sound shield (422 hours)

• Low resistance, copper wire and sacrificial zinc anode bonding system.

(2) 12-volt house batteries for a total of 420-amps.

• Start – Two 12-volt AGM Group 31 batteries with 950 CCA capability.

• House – Two 12-volt AGM Group 4D batteries – 210-amps each.

• Heavy-duty battery parallel switch allows emergency starting.

• (2) Two 185 amp 12 Volt D.C. alternators, one for house batteries and one for each starting battery

• 12-volt distribution panel includes thermo-magnetic breakers, volt and amp meter.

110-volt AC electrical system

• 110-volt shore power inlet and relay.

• (2) 30 amp shore power cord.  (1) dedicated to house and charging loads and (1) dedicated to climate control systems

• Victron Multiplus inverter/charger with 100-amp 12-volt multi-stage battery charging capability.

• 3000 watt pure sign wave inverter with control mounted in cabin

• Optional 110 volt outlet located at port helm

Engine/Mechanical

• Twin Yanmar 8LV 370hp diesel engines

• Optional Algae-X conditioners for engines and generator

• Hamilton 274 Jet Drives

• Twin ZF 63 transmissions

• 7” hydraulic variable thrust bow thruster

• Hinckley custom “JetStick II®” control system is integrated with the bow thruster

• Dual cylinder trim tabs with indicator controls at helm

• Fuel filter/water separator with audible alarm panel at helm

• Fuel, oil pressure, and water temperature gauges.

• Alarms for high-low oil pressure, and high engine water temperature and hydraulic pressure

• Manual hydraulic steering pump.

• (3) Electric 1500-GPH 12-volt bilge pumps with float switches and high water alarm

• Whale emergency bilge pump - mounted in cockpit locker.

• In-line 12-volt automatic shower sump pump.

• 27-gallon holding tank with overboard discharge.

• 6-gallon stainless steel hot water heater – shore power and engine heated.

• 40-gallon polyethelelene water tank.

• (2) 110-gallon polyethelene fuel tanks - total 220-gallons.

• Mylar-faced acoustical foam-lined engine box insulation.

• Engine box cover has double gaskets and an electric riser.

• Engine box forced-air exhaust fan.

• Baffled and insulated air intake

• Automatic engine compartment fire suppression system, with automatic engine shut-down

• Optional overboard waste discharge
